IV Catheter
Enquire Now
Curacan Open IV Cannula (Port Type)
Curacan Open IV Cannula (Port Type) includes an injection port for convenient medication administration without additional puncture.
Key Features
- Back-cut V shaped needle, make sure the first-insertion success with less tearing and fast healing
- Double flashback technology improves the first-insertion success
- PU Catheter reducing the injury of blood vessels and lower the incidence of mechanical phlebitis
- DEHP free
Specifications
| Code No. | Gauge | Catheter Length | Catheter OD (mm) | Gravity Flow Rate (ml/min) | |
|---|---|---|---|---|---|
| (in) | (mm) | ||||
| IVC01A-18 | 18G | 1.25 | 32 | 1.3 | 105 |
| IVC01A-20 | 20G | 1 | 25 | 1.1 | 60 |
| IVC01A-22 | 22G | 1 | 25 | 0.9 | 35 |
| IVC01A-24 | 24G | 0.75 | 19 | 0.7 | 22 |
